Fiber Laser Cutting Machine

The fiber laser cutting machine for sale, also known as the metal laser cutting machine or metal laser cutter, is the laser machine adopting fiber laser source to cut steel, carbon steel, stainless steel, copper, brass, aluminum, iron, galvanized steel, titanium and various alloys. It has wide applications in metal part, equipment, ship, and automotive manufacturing, advertising signs, sheet metal structure, kitchenware, metal furniture, custom metal fabrication, and other fields. Check the 2022 best fiber laser cutting machine buyer’s guide for beginners and metal workers.

The fiber laser cutter, based on functions, falls into the laser cutting machine for metal sheet, fiber laser tube cutting machine, and sheet and tube laser cutting machine. Each model of the fiber laser machine has multiple specifications and configurations.

Based on the fiber laser power, we provide 1000W / 1500W / 2000W / 3000W / 4000W / 6000W / 8000W fiber laser cutting machine and other high power laser cutting machines to realize your metal cutting designs, ideas, and plans.

In addition, there are multiple worktable sizes available for the laser sheet cutting machine. For example, 1530 fiber laser cutting machine, 1540 laser sheet cutting machine, 2040 CNC fiber laser cutter, 1560 sheet metal laser cutter, 2040 fiber laser cutting machine , 2060 fiber laser cutter, etc. Feel free to contact us if you want to know more about the fiber laser cutting system or the laser cutting service.

Fiber Laser Cutting Machine Related Videos

Fiber Laser Cutting Machine Buyer Guide

What is the fiber laser cutting machine?

A fiber laser cutting machine is a mechanical CNC cutting machine that uses a fiber laser beam to cut materials. Its high-energy-density laser beam comes from the fiber laser generator and transmits by fiber cables instead of optical lenses. The wavelength of the fiber laser cutting system is 1.06um, which can be absorbed by most metal materials. So a fiber laser cutter is mainly for cutting a wide range of metals, such as steel, aluminum, brass, titanium, nickel, etc.

What is a fiber laser generator?

The fiber laser generator is one of the core components of the laser metal cutting machine. A fiber laser generator is a laser that uses rare earth element doped glass fiber as the gain medium. The pumped light enters the gain fiber and is absorbed, which in turn reverses the number of energy level particles in the gain medium. When the gain in the resonant cavity (consisting of two reflective lenses) is higher than the loss, laser oscillation will form between the two lenses, producing a laser signal output.

Advantages of CNC fiber laser?

1. Good beam quality.

The waveguide structure of the fiber laser determines that it is easy to obtain a single transverse mode output. Besides, it is unlikely to be affected by external factors, which can achieve high brightness laser output.

2. High efficiency.

The overall electro-optical efficiency of commercial fiber lasers is as high as 25%, which is conducive to cost reduction, energy-saving, and environmental protection.

3. Good heat dissipation.

The CNC fiber laser uses thin rare earth element doped fibers as the gain medium, which has a very large surface area to volume ratio. This is conducive to heat dissipation. The water-cooling method for high-power fiber laser can avoid the loss of quality and efficiency caused by the heat effect.

4. Compact structure and high reliability.

Since the fiber laser uses fine and flexible fiber as the gain medium, it helps to compress the size and save cost.

5. Maintenance free.

There is no optical lens in the resonant cavity of the CNC fiber laser. So it has the advantages of adjustment-free, maintenance-free, and high stability, which is incomparable to traditional lasers.

How does the fiber laser cutting machine work?

A fiber laser cutter cuts the metal sheet by a high-density beam with the non-contacting method. The laser generator generates a fiber laser beam, which is focused into a light spot and irradiated to the surface of a workpiece. The area irradiated by the light spot of the workpiece will heat up sharply, and melt or vaporize instantaneously. Under the control of the computer numerical system, the light spot moves along a given path to form a slit. Meanwhile, the auxiliary gas blows off the cutting slag.

Therefore, a fiber laser cutter is high-tech equipment integrating laser technology, computer control technology, and precision equipment technology.

Classification of fiber metal laser cutting machine

The metal laser cutting machine can be classified according to different criteria. Here are some classifications of fiber laser machines based on industry requirements.

According to processing materials, the metal laser cutter is also called the laser iron cutting machine, steel fiber laser cutter, stainless steel laser cutter, steel laser cutting machine, aluminum laser cutting machine, and so on.

Based on fiber laser power, we provide 1000W fiber laser cutting machine, 1500W laser cutting machine, 2000W laser cutting machine, 3kW laser cutting machine, 4kW laser cutting machine, 6kW laser cutting machine, 8kW fiber laser cutting machine, 10kW fiber laser cutting machine, and other high power laser cutting machines to realize your metal cutting designs, ideas, and plans.

To classify in line of functions, the metal laser cutting machine falls into the laser pipe cutting machine, fiber sheet cutting machine, and sheet and tube laser cutting machine.

In terms of the processing format, we provide 1530 fiber laser cutting machine, 1540 laser sheet cutting machine, 1545 CNC fiber laser machine, 1560 metal fiber laser machine, 2040 metal laser cutting machine, 2050 fiber laser metal cutting machine, 2065 metal laser cutter, etc. for the metal plate fiber laser cutting machine.

What are the major parts of a fiber laser cutting machine?

The fiber laser cutting machine for sale has the advantages of fast speed, high precision, and easy maintenance. So it has extensive applications in the metalworking industry. A CNC fiber laser cutter consists of the following major parts.

Main machine. The main machine of a fiber laser machine refers to the bed, beam, worktable, Z-axis system, gas control system, electric control system, transmission system, protective housing, and safety system. It also refers to the whole fiber laser cutting system. During laser cutting, the workpiece is placed on the worktable first. Then the beam is driven by servo motors to control the movement of the Z-axis. Furthermore, users can adjust the parameters of the fiber laser CNC machine according to their needs.

Fiber laser. This is the core part of a metal laser cutter. It is also the power source to realize the laser cutting operation. The fiber laser has higher photoelectric efficiency, longer service life, less maintenance, and lower cost compared with other lasers. We provide multiple options of fiber laser for customers to choose from. For example, IPG fiber laser, Raytools laser, WSX laser, Precitec laser, Ospri laser, etc.

Cutting head. The laser cutting head is a laser output device, which consists of a nozzle, focusing lens and focusing tracking system. The cutting head of a fiber laser cutting machine will move according to the set cutting path. But the laser cutting head focal position varies according to different materials, thicknesses, and cutting modes.

Control system. It mainly controls the movement of X, Y, and Z axes of a metal laser cutting machine. Besides, it can also control the cutting power, cutting speed, and other parameters.

Cooling system. It mainly consists of a water chiller used to cool the laser generator. For instance, if the electro-optical conversion rate of the laser is 33%, there are about 67% of the electrical energy converted to heat. To ensure the normal operation of the laser cutting equipment, the chiller needs to reduce the temperature of the whole machine through water cooling.

Gas supply system. The gas supply system of a fiber laser metal cutting machine includes the gas source, filter device, and pipes. Cutting different metals may require different types of gases.

What are the vulnerable parts of the laser head of a fiber laser cutting machine?

We all know the fiber laser machine requires less maintenance than other laser machines. Even so, you also need to pay attention to its daily use and maintenance. Especially the laser head requires your special attention because it has several vulnerable parts.
The vulnerable parts of the laser head include the collimation protection mirror, focus protection mirror, nozzle, and ceramic ring.
Service life of the laser head vulnerable parts (under continuous cutting):

  • Collimation mirror: 640h per piece
  • Focus protection mirror: 160h per piece
  • Nozzle: 240h per piece
  • Ceramic ring: 2000h per piece

Note: The above service hours are theoretical data and are subject to the actual cutting conditions of customers.

Technical parameters of a fiber laser cutting machine

  Sheet metal laser cutting machine Laser pipe cutting machine Sheet and tube laser cutting machine
Laser type Fiber laser
Laser IPG, Raycus, GW, auto or manual focusing optional
Laser power 1000W, 1500W, 2000W, 3000W, 4000W, 6000W, 8000W, 10000W fiber laser
Worktable area 1530, 1540, 1545, 1560, 2040, 2060, 2560 6161/9160, 6220/9220, 6350/9350 1530, 1545, 1560, 2040, 2060
Max. running speed 140m/min
Max. acceleration 1.5G, 2.0G 1G 1.5G
Positioning accuracy ±0.03mm
Repositioning accuracy ±0.02mm
Application Steel, aluminum, copper, brass, nickel, titanium, galvanized sheets, tubes and pipes

How much does a fiber laser cutter cost?

Judging from the current market price of fiber laser cutting machines, the price of a medium and low power fiber laser cutting machine is about USD10,000 to 100,000. Besides, a high power laser cutting machine could cost over $100,000. We know that the specific price of a fiber laser cutting machine is affected by many factors. Generally speaking, the larger the working area, the higher the configuration, and the higher the power, the higher the fiber laser machine price.

The following table shows the general range of the fiber laser machine price. It can be seen that the quotation of the Blue Elephant fiber laser cutting machine is about USD 10,000 to 100,000. Even for the same model, the larger the worktable and the higher the laser power, the higher the fiber cutting machine price.
Model Fiber laser cutting machine price
Laser sheet cutting machine $10,000-$90,000
Fiber laser tube cutting machine $9,000-$50,000
Sheet and tube laser cutting machine $20,000-$90,000
Fiber laser machines with different powers also vary greatly in price. For example, 1000W fiber laser cutting machine price ranges from $15,000 to $35,000 with different worktable sizes. A Raycus 1500W laser cutting machine of 1530 model could cost you about $25,000. The price of a 4000W laser cutting machine is about $35,000 to $40,000. Our 1530 fiber laser cutting machine with a power of 6kW could cost you over $60,000. A 10kW fiber laser cutting machine will cost you over $100,000.

Factors affecting the fiber laser cutting machine price

Let me introduce the main factors affecting fiber laser cutting machine price:
  1. Production cost

    The production cost mainly refers to the cost of each component of the fiber optic machine. If the quality of the components of the fiber laser cutting machine is good, the production cost of the fiber laser is relatively higher. Therefore, the laser cutter price is naturally higher.
  2. Model

    There are many types of laser cutting machines. Generally speaking, the larger the fiber laser cutting machine, the greater the production output, the higher the economic benefits to users, and the more expensive the price.
  3. Technical content

    The technical content of the fiber laser cutter will affect the production efficiency and service life of the fiber laser cutting machine, as well as the price of the equipment. The higher the technical content of the equipment, the higher the production process, the better the performance of the equipment, the higher the quality, and the better the quality of the metal parts produced. Therefore, the higher the technical content of the laser cutting machine, the higher the price.
  4. Purchasing method

    When users purchase fiber laser cutting machines, the common purchasing method can be divided into online and offline purchases, direct sales, and distribution purchases. The prices of different purchase methods are different. It is recommended that users choose a combination of online and direct sales. The so-called online refers to online consultation and selection of brand selection. Generally, Blue elephant manufacturers advocate offline transactions, which can not only reduce costs but also ensure equipment quality.

Application of the fiber laser cutting machine

Fiber laser cutting machines can cut many kinds of metal plates and tubes. It is mainly suitable for cutting stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized plate, aluminized zinc plate, pickled plate, copper, silver, gold, and other metal plates and tubes.

The fiber laser cutting machine has wide application fields. For example, thin metal sheet processing, advertising signs, electric cabinets, mechanical parts, kitchenware, automobile, equipment, crafts, arts, electronic boards, medical equipment, instruments, tools, etc.

Why choose the fiber laser cutting machine?

  1. High cutting accuracy.

    The positioning accuracy of the metal laser cutter reaches 0.03 mm, and the repeated positioning accuracy reaches 0.02 mm.
  2. Narrow slit.

    The width of the slit is generally 0.10-0.20 mm.
  3. Smooth cutting surface.

    There is no burr on the cutting surface, and the roughness of the cut surface is generally controlled within Ra6.5.
  4. Fast cutting speed.

    The cutting speed of a fiber laser cutter can reach 60m/min. And the maximum running speed of a fiber laser metal sheet cutting machine can reach 140m/min.
  5. Good cutting quality:

    Adopting non-contact cutting, there is basically no thermal deformation and damage of the workpiece. Besides, the cutting surface generally requires no further processing.
  6. Flexible operation.

    The fiber laser cutting machine has good flexibility to cut any patterns. It can also cut various regular and irregular-shaped tubes and steel bars.
  7. Long service life.

    A top-rated fiber laser has high photoelectric conversion rate and stable performance. The service life of the major parts of a fiber laser cutting machine could reach 100,000 hours.
  8. Less maintenance.

    The laser of laser metal cutters for sale is transmitted by optical fibers instead of optical lenses. So there is no need to adjust the optical path and replace lenses frequently, which reduces many maintenance costs.
  9. Strong adaptability.

    The laser cutting machine for metal sheet is capable of handling any harsh working environment. It also has strong adaptability to dust, vibration, impact, humidity, and temperature.

Advantages of CNC fiber laser cutting machine

CNC Fiber laser cutting machine has many advantages. For instance, fast cutting speed, high precision, small heat affected area, stable performance, guaranteed continuous production, smooth cut seam, and less maintenance.

Compared with other metal laser cutters, a fiber laser cutter can complete the processing of various complex structures. As long as we can draw 2D images by the software, the fiber laser machine can cut metal materials without molding. And the products are produced immediately. This improves work efficiency, reduces operation costs, and saves human labor. No matter how complicated the process requirements are, these laser cutting machines can do it.

The fiber laser cutting machine is famous for its high efficiency and good cutting quality for cutting metal sheets, pipes, tubes with thickness less than 4 mm.

Fiber laser cutter VS CO2 laser cutting machine

CO2 laser cutting machine is also a commonly used laser cutting machine for industrial purposes. But in actual use, there are big differences between a CO2 laser cutting machine and sheet metal laser cutting equipment. The differences mainly include the following aspects.

1. Laser generator

The CO2 laser generator is a kind of gas molecular laser. It uses CO2 gas as the medium and transmits the laser beam through reflective lenses. However, fiber laser cutting machines work with diodes and fiber optic cables for beam transmission.
The reflective lenses in the CO2 laser technology have to act at a certain distance. While the CNC fiber laser is not subject to such limitations.

2. Electro-optical conversion rate

Fiber laser cutting system is the latest laser technology. Its solid-state laser generator is more efficient than a CO2 laser. The electro-optical conversion rate of a CO2 laser cutter is only 8%-10%. However, that rate of a fiber laser cutter can be as high as 30%. In other words, the overall energy consumption of a metal laser cutting machine is 3-5 times lower than that of a CO2 laser cutter. So the fiber laser machine is more energy-efficient.

3. Cutting ability

Fiber laser has the property of short wavelength, thus improving the absorption of the beam by the cutting material. The fiber laser beam is more suitable for transmission in the fine and soft fiber. So it is more flexible and easier to maintain than the CO2 laser transmission with mirror reflection. A 3KW fiber laser cutting machine is equivalent to a 4-5KW CO2 laser cutting machine in terms of cutting capacity and speed. So the metal laser cutter can greatly reduce operating costs.

4. Maintenance cost

As a CO2 laser cutter has a complex laser structure, its subsequent maintenance cost is relatively high. The CO2 laser cutting system requires regular cleaning, and the reflective lenses also require frequent cleaning and calibration. Due to the CO2 gas purity, you need to maintain the resonant cavity regularly. However, a CNC metal laser cutter doesn’t require the above maintenance, saving a large amount of cost.

4. Application

Fiber laser cutting machine is mainly for metal cutting, such as mild or carbon steel, stainless steel, aluminum and its alloys, brass, copper, titanium, etc. While the Co2 CNC laser cutting machine is good at cutting non-metallic materials. It is now a solution to cut or engrave acrylic, wood, MDF, glass, etc.

Fiber laser cutter VS YAG laser cutter

YAG laser uses a lamp (bulb) as the pumping mechanism and a YAG crystal as the gain medium. Similar to a fiber cutting machine, the YAG laser cutting machine is also for metal cutting. But they also have some differences in the following aspects.

1. Cutting efficiency

A YAG laser cutting machine is relatively cheaper than a CNC fiber laser cutter. It is able to cut highly reflective materials, such as aluminum, copper. Though customers still utilize YAG lasers in manufacturing, this laser design is becoming obsolete because the bulbs have a short lifespan and require frequent replacement. Its cutting efficiency is much slower than a fiber laser cutting machine.

2. Cost

YAG laser has been developed for many years, so the YAG laser cutting machine price is relatively cheaper than a fiber laser CNC machine. But with the development and popularity of fiber lasers, this price advantage has been weakened. Besides, the YAG laser cutter consumes much power during operation, which incurs additional operating costs. However, the operation cost of a fiber laser cutting machine is low although with a high initial investment.

3. Maintenance

There is no optical lens in the resonant cavity of the fiber laser. So the laser sheet cutting machine has the advantages of adjustment-free, maintenance-free, and high stability. While YAG laser cutter requires frequent replacement of the bulb and other parts.

Precautions for buying a fiber laser cutting machine

Requirements of the fiber laser cutter

First, you need to know whether the fiber laser cutting machine meets the cutting requirements. Such as the maximum size of the processed sheet, the material, the thickness of the sheet that can be cut, and the size that can be completed. All in all, the equipment should be selected according to the company’s own processing technology requirements, and the fiber laser cutting machine that can properly meet the company’s own processing level is the best choice.

Fiber laser cutting accuracy

Some customers received misleading advice from others, saying that the laser cutting accuracy can reach within 0.5 mm. So they buy the fiber laser cutting machine blindly. But it turned out that it is not the case. For CNC equipment, the marking accuracy is generally within 0.5mm, while the cutting accuracy is generally within ±0.05mm. So customers must inquire and investigate more when purchasing.

Fiber laser cutting machine prices

This is a very critical question. In the face of all kinds of metal laser cutting machines on the market, how to choose? Many customers have a fluke mentality and spend low prices to buy good equipment. This is a bit unrealistic. You get what you pay for, and buying low-priced equipment will only increase costs, not reduce costs, or improve efficiency.

Fiber laser cutting quality

The quality of fiber metal laser cutting machine is a problem that customers worry about. To solve this problem, customers can go to the factory site to watch their production process. Through the production process, you can see the scale of an enterprise and the quality of the equipment.

After-sales service

The motherboard is composed of electronic components. For a system composed of electronic components, can there be no problems? I believe that no manufacturer can guarantee that their products will not have any problems. If problems occur, the fiber laser cutting machine manufacturer shall be able to give solutions in time. Therefore, it is necessary to investigate the after-sales service conditions of the fiber laser cutting machine manufacturer before buying.

Factors affecting the cutting quality of a fiber laser cutting machine

Fiber laser CNC machine has the characteristics of narrow cutting slit and smooth cutting edge. However, in practice, it is likely to get a cutting effect that is not satisfactory due to certain factors. Many factors could affect the cutting quality of the metal laser cutting machine.

Cutting speed, adjustment of the focal position, auxiliary gas pressure, laser output power, and workpiece characteristics are some of the main factors. In addition, the workpiece clamping device is also crucial to ensure the quality of the cut. Because during the laser cutting process, heat and stress will release throughout the workpiece. Therefore, you must consider an appropriate clamping method to avoid moving or sliding the workpiece for your fiber laser cutting machine.

What's more, there are also other factors affecting the fiber laser cutting quality. For instance, the choice of a nozzle, the diameter of the nozzle, and the distance between the nozzle and the workpiece surface. In addition, the optical path also has an effect on the cutting quality of a metal laser cutter.

How to solve the burrs of fiber laser cutting?

Burrs occur on the cutting edge when there is something wrong with the fiber sheet cutting machine. We list several possible reasons and related solutions to solve this problem below. So you can check your fiber cutting laser machine initially according to the following solutions when burrs occur. If the problem still exists, please contact your CNC fiber laser cutting machine supplier.

1. Deviation of the upper and lower positions of the laser beam focus

Solution: Adjust the focus position according to the deviated position.

2. Insufficient output laser power

Solution: Check if the fiber laser metal sheet cutting machine works normally. If no, repair and adjust in time. Besides, check the output laser power if the machine works normally.

3. Slow line cutting speed of the laser cutter machine

Solution: Adjust and increase the line cutting speed in time.

4. Insufficient purity of the auxiliary gas of the steel fiber laser cutter

Solution: Increase the purity of the auxiliary gas.

5. Long-time operation of the metal cutting laser machine for sale

Solution: Stop the machine to let it get rest for a while, and then reboot the machine.

How to maintain the fiber laser metal cutting machine?

The fiber laser cutting system mainly includes the circuit system, transmission system, cooling system, light source system, and dust removal system. So, the daily maintenance shall focus on ensuring the constant cooling effect, dust removal effect, quality of the beam, and normal operation of guide rails. In addition, a good working environment and correct operating habits are also conducive to extending the service life of the equipment. Remember the following four steps to keep your fiber laser cutter machine in good condition.

Keep the steel belt tight at all times.

Steel belt in the operation of the laser cutter machine plays a very important role in the transmission. The workpieces are easily thrown off the track if the steel belt in the operation is not tightened. Besides, the steel belt may slip, which is a hidden danger to the operator. Therefore, the steel belt should be kept tight at all times.

Check the angle of the laser cutting head frequently.

You may need to adjust the laser cutting head if you often cut different materials. As one of the most important parts of a metal laser cutting machine, the laser head has a great influence on the cutting quality. Long-term use or improper use of the laser head may cause deviation, thus causing poor cutting accuracy. So you need to check and adjust the laser head regularly.

Keep the laser metal cutters for sale clean.

Pay attention to removing the dust if you use your fiber laser machine in a not very clean workhouse. Dust will make our machine operation become raw and increase the friction between accessories. Besides, it also increases wear and tear. Frequent dust cleaning of the tube and sheet metal laser cutting equipment is good for our cutting machine to maintain accuracy from time to time.

Frequently lubricate the fiber laser cutting machine.

We need to lubricate the racks, guide bars, and many parts of the fiber cutting machine from time to time. This can maintain the accuracy of the gears in the operation of engaging. In addition, the operation of the machinery will be in the normal operation, ensuring high cutting precision.

Comparison of laser metal cutting machine with other metal cutting machine solutions

With the rapid development of metal cutting technology, the metal cutting solution is also changing day by day. Various high-tech and high-efficiency metal cutting machines are used to cut metal materials or provide metal cutting services. The traditional metal cutting machines mainly include CNC shears, punching machines, flame cutting, CNC plasma cutting, water-jet cutting, and fiber laser cutting machines.

CNC shearing machine

The CNC shearing machine is a type of forging and pressing metal cutting machine. It is mainly for the linear cutting of metal sheets. Although it can cut plates up to 4 meters long in one cut, it can only be used for linear sheet metal cutting. The CNC shears have low operation costs, high efficiency, and good precision. It is generally used in metalworking industries that require only straight-line cutting, such as cutting after sheet flattening.

CNC punching machine

CNC punching machines offer more flexibility in curve metal cutting solutions. There is one or more sets of the square, round, or other special punches in one CNC punching machine. You can use these punches to cut simple straight, circular, or square shapes. It is mainly for cutting steel sheets under 2mm thick. But it has limitations for punching steel plates with a thickness of over 2mm. Besides, the processing quality and noise are not satisfactory.

CNC flame metal cutting machine

As a traditional metal cutting machine, the flame cutting machine has still been used widely to cut thick metal sheets. For example, it is mainly used to cut metal sheets 40mm thick or above. However, the flame cutting often causes great thermal deformation, wide cutting slits, and large material waste. So it is only suitable for the rough processing of metal cutting.

CNC plasma cutting machine

Similar to the CNC flame cutting, plasma cutting machines also have big heat-affected areas. But the cutting precision and speed of a plasma cutting machine have been improved greatly. So it has gradually replaced the flame cutting machine in cutting thick metal sheets. Its thermal deformation and cutting slope is big. Besides, it can meet the high cutting accuracy.

Water-jet metal cutting machine

The water-jet has nearly no limitation on the cutting metal and it can cut metal sheets of over 100mm thick. It can also cut ceramics, glass and other materials that are easy to explode when cutting with thermal cutting method. However, the water-jet metal cutting method has too slow cutting speed and requires a large amount of water, which is not environmentally friendly.

Laser metal cutting machine

The laser metal cutting machine has become the most popular machinery in the metalworking industry. That’s because it has many advantages over the other traditional metal cutting machines.

Improved performance and security

A metal laser cutting machine has a higher safety level, faster speed, and higher efficiency than other machines. It is capable of continuous working without special maintenance. This controls the operation cost to a large extent.

Better cutting precision

The fiber laser cutting machine has better cutting accuracy than any other metal cutting equipment. Its cutting edges are more flat, clean and smooth. The fiber laser machine avoids material waste caused by poor cutting accuracy and saves production and operation costs.

Does a fiber laser cutting machine need an air compressor?

A fiber laser cutting machine is able to cope with the requirements of cutting a wide range of materials and complex shapes. In addition to a laser capable of delivering high energy, auxiliary gases are essential to the cutting process. There are three main auxiliary gases used for laser cutting: oxygen (O2), nitrogen (N2) and compressed air. Compressed air is more readily available than oxygen and nitrogen. What’s more, it is very inexpensive compared to the former two gases. So it is very common to use compressed air as an auxiliary gas for fiber laser cutting. Therefore, if you choose to use cheap compressed air for your fiber laser cutter, then you will need an air compressor.

The quality of compressed air has a direct influence on the cutting quality of a metal laser cutter. Besides, the air pressure and stability also affect the cutting results. Thus, the choice of the air compressor specifications mainly depends on the laser cutting head design, air pressure, and nozzle size used by the fiber laser cutter. In such cases, you can get the most suitable air compressor for your laser metal cutting machine.

Compressed air can be supplied directly from the air compressor, which is more accessible and cheaper than O2 and N2. Although air contains only about 20% oxygen, cutting efficiency is much less than oxygen cutting. However, the cutting efficiency of a fiber cutting machine with compressed airy is slightly higher than that with nitrogen. The cut surface may appear yellow when the fiber laser cutting machine use compressed air as the auxiliary gas. So, using compressed air may be the best economical choice for a metal cutting laser machine when there is no strict requirements for the cutting surface color.

Installation guide for a fiber laser cutting machine for metal sheets

When packing our fiber laser cutting machines, many of the connecting cables are separate from the equipment. This makes it easier to transport over long distances. Therefore, when you receive the fiber laser machine, you need to connect the wires of each part. The whole assembly and connection process is not complicated, because there are simple instructions on our machines. And all the connecting wires of the metal laser cutter are neatly arranged, which is conducive to the installation. Besides, we will also provide installation videos and instructions for you. So even if you know little about the machine assembly, you'll assemble your fiber laser cutter for metal easily. The following installation steps apply to the installation of a 1530 fiber sheet metal laser cutting machine.

#Step 1: Fan connection

Connect the wires of the fan to the control cabinet. Connect the pipes to the fan and the fiber laser cutting machine. The fan is used to exhaust the smoke and fume generated from the fiber laser cutting system.

#Step 2: Water chiller connection

Connect various water pipes to the relevant inlet and outlet positions successively. The transparent pipes connect the water chiller and the fiber laser cutting machine. In addition, the red pipe connects to the water inlet and the blue to the water outlet. Connect the wires of the water chiller to the control cabinet of the fiber laser cutter. There are labels on the wires in order to facilitate the wire connection. So pay attention to the labels and make sure to connect the right wires.

#Step 3: Gas supply

Connect the pipes property to the gas supply system, such as oxygen or nitrogen cylinder, air compressor.

#Step 4: Main power supply

Properly connect the main power cable to ensure power supply for the whole fiber laser cutting system. Then switch on the main machine, water chiller, and fiber laser successively to check if the power supply is normal.

What's the operation cost of a laser metal cutting machine?

As we mentioned before, the fiber laser cutter has many advantages that other metal cutting machines cannot match. For example, high efficiency, excellent precision, and good cutting results. But these advantages are also reflected in the manufacturing costs of a fiber laser cutting machine. The fiber laser cutting machine price is relatively higher than the price of other metal cutting machines with the same power. So, the initial investment for a fiber cutting machine is higher than other metal cutting equipment. However, the operation cost of a fiber laser machine is much less than other metal cutting machines.

The operation cost of a metal laser cutting machine mainly includes electricity fees, auxiliary gas fees, and spare part costs. The electricity consumption mainly depends on the power of every major component of the metal laser cutter. For example, a 2000W fiber laser consumes 30KVA and a 4000W fiber laser consumes 50KVA. The higher the power, the greater the power consumption. Besides, the mechanical parts, water chiller, air compressor, smoke remover, and other devices also consume a small amount of energy. But in general, the electricity consumption won't be big due to the high photoelectric efficiency.

The auxiliary gases won't cost you too much. Besides, compressed air is more cheaper than oxygen and nitrogen. Furthermore, the fiber laser cutting machine requires less maintenance than other metal cutting machines. But you may need to replace the protection lens, nozzle, and ceramic ring of the laser head after a long time of use to keep the cutting accuracy.

In short, although a fiber laser cutting machine needs high initial investment, the operation and maintenance will save you much money than other metal cutting equipment.

What are the safety protection measures of a fiber laser cutter?

Nowadays, the use of laser cutting machines in various industries is increasing. So some necessary protective measures are required during the laser cutting process to avoid unnecessary injuries.

Fire prevention

Smoking should be prohibited in the cutting machine area of the fiber laser cutter, especially near the oxygen cylinder. This helps prevent unnecessary damage caused by hidden dangers. We recommend having a dedicated fire extinguisher near the laser cutting stainless steel machine.

Cutting protection

Make sure that there are no personnel and flammable and explosive foreign objects around the worktable. This can avoid unnecessary injury and loss caused by sparks during operation. Besides, you can choose safety light curtains for your fiber laser machine. The photoelectric safety device generates a protective light curtain by emitting infrared rays. When the light curtain is blocked, the device sends a light-blocking signal to control the sheet metal laser cutting equipment to stop working to avoid safety accidents. It can effectively protect human safety and avoid production accidents.

Emergency situation

Press the Emergency Stop button immediately to shut down the fiber laser cutting system in case of any emergency matters.

Power supply

The fluctuation of the power supply voltage will cause unstable laser cutting. Excessive voltage can cause permanent damage to the power supply system of the laser metal cutting machine. We recommend customers use a voltage stabilizer in order to prevent the electrical appliances and circuits from being burned. Especially the areas where line failures often occur.

Environment temperature

The working temperature of the fiber laser cutting machine is required to be below 40°C. Because the failure rate of the fiber laser cutting system will increase when the room temperature is too high. Therefore, the ambient temperature should preferably be controlled above 5°C, but not exceed 35°C. Also, the water used in the water chiller may freeze in winter. So you may use antifreeze or other measures to prevent the water from freezing.
