3D ATC CNC Wood Router with a carousel tool changer can change more than 8 sets of tools automatically in the Wood engraving process. It mainly for heavy-duty and automatic woodworking, cause it can greatly save time, fewer people and time needed for machine operation. 3D ATC CNC Wood Router Machine for sale at cost price.
1. Equipped with an Italy HSD ATC air cooling spindle and carousel tool changer for a faster tool shifting.
2. Global quality CNC parts guarantee stable performance and high finishing quality.
3. Rigid vacuum table with grids and T-slots help you clamp the workpiece in place.
4. 3 axis woodworking CNC router is suitable for more complex 3D surface processing.
| Model | ELECNC2060ATC |
| X,Y axis travel | 2000x6000mm, option: 1300x2500mm, 1500*3000mm; 2100*3000mm; 2100*4000mm, etc |
| Z axis travel | 200mm, option: 300mm, 400mm, 500mm, 600mm, etc |
| Spindle type | 9kw ATC air cooling spindle, ISO30, ER32 |
| Inverter type | 11kw |
| Drilling bank | Taiwan or Italy 5+4 vertical drills |
| Tool magazine | Linear type auto tool changer Option: carousel type auto tool changer |
| Tool holder with collet | ISO30, ER32 collet: φ4, φ6, 1/8, 1/2 |
| Control system | Taiwan SYNTEC / LNC controller, option：Ncstudio |
| Driving system | 1kw Japan YASKAWA AC servo driver and 850w AC servo motor, 4 sets. option: 1kw Taiwan Syntec servo |
| Reducer | Japan SHIMPO reducer |
| Machine structure | Heavy duty body with quenching treatment |
| Work table | Aluminum T-slot & vacuum work table |
| Positioning cylinder | 5 pieces (X2, Y3) |
| Linear guide | Taiwan #25 Linear guide with dust proof |
| Transmission | X, Y axis: Taiwan /Germany Helical Rack and Pinion Z axis: Taiwan TBI high precision ball screw |
| Lubrication system | 1.5L automatic lubrication system |
| Tool calibration | Automatic tool sensor calibration |
| Cables | Germany Igus cables with CE, cUL certificate |
| Compatible software | Artcam, Alphcam, Type 3, Ucancam, Aspire, etc |
| Command language | G Code & M Code |
| Traveling speed | 80m/min |
| Working speed | 0-25m/min |
| Re-positioning accuracy | ±0.03mm |
| System resolution | ±0.0025mm |
| Working accuracy | ±0.03mm |
| Working air pressure | 0.6MPa |
| Working voltage | 220V 1PH/3PH 50HZ/60HZ 380V 3PH 50HZ/ 60HZ |
| Vacuum pump |
Tongyou, Taiwan Eurovac, Germany Becker |
| Dust collect system |
|
| Air compressor | Piston air compressor, screw air compressor |
| Protection device | Light curtain |
| Spindle type | 9kw ATC spindle (HSK F63),12kw (ISO30, HSK F63), etc |
For a 3-axis CNC machine, the standard travel of the Z axis is 200mm. If you need, we can customize a higher Z axis for you.
ATC means Automatic Tool Changer. With it, the CNC machine can change bits automatically and greatly improve the working efficiency.
Yes, you can. The machine details can be changed as you wanted. Our factory can design the CNC machine according to your requirements. We will provide you with the most suitable CNC machine.
